Dynamic Data Sources Based on Cluster Rules

In the last post we saw how to run regression with Data Miner, interpret its results and how to use cluster information to filter regression data sources. It was quite a laborious task - even with a small number of clusters. If we want to experiment with the number of clusters, clustering methods and their parameters, and feed those clusters dynamically into regressions, we would need to run regressions programmatically.

Let’s start with a case of a simple regression ran by DBMS_DATA_MINING package. Again, I’ll refer the reader to “Predictive Analytics Using Oracle Data Miner” by Brendan Tierney or to his blog for step by step instructions of orchestrating data mining workflows with PL/SQL. Basically in order to run regression with PL/SQL instead of using DataMiner UI, you need to:

  • Create a table for regression settings
  • Populate that table with settings
  • Define a data source (a view in our case - V_REGRESSION_ACC_002)
  • Create the model with DBMS_DATA_MINING package
  • Query results


--Here’s the settings table
CREATE TABLE REG_SETTING_002 (SETTING_NAME VARCHAR2(300), SETTING_VALUE VARCHAR2(4000));

Begin

Insert into REG_SETTING_002 (SETTING_NAME,SETTING_VALUE) values (dbms_data_mining.algo_name,dbms_data_mining.algo_generalized_linear_model);
commit;

--Create the model
SYS.DBMS_DATA_MINING.CREATE_MODEL(
model_name=>'REGRESSION_ACC_002',
mining_function=>dbms_data_mining.regression,
data_table_name=>'V_REGRESSION_ACC_002',
case_id_column_name=>'CASE_ID',
target_column_name=>'12346_ACC',
settings_table_name=>'REG_SETTING_002'

);
end;
/


The data source 'V_REGRESSION_ACC_002' would have a WHERE clause with cluster definition. In other words the following filter should be applied:

And "BUSINESSUNIT" IN ('B_xxxx', 'B_xxxy', 'B_xxxz', ...)
and "COSTCENTER" IN ('C_xxxx', 'C_xxxy', 'C_xxxz', ...)


How that cluster rule can be queried? I’ll refer to Brendan’s blog for rule query and to Tom Kyte blog for converting multiple rows into comma separated list. In our case the query for cluster 8 and rule for COSTCENTER dimension would be:

with t1 as (
select t.id,
      a.attribute_name,
      a.conditional_operator,
      nvl(a.attribute_str_value,
      a.attribute_num_value) AS atrvalue,
      a.attribute_support,
      a.attribute_confidence
from TABLE(dbms_data_mining.get_model_details_km('CLUS_KM_1_2'))  t,
    TABLE(t.rule.antecedent)  a
where 1=1
and t.id = 8
and a.attribute_name='COSTCENTER'
)

SELECT SUBSTR (SYS_CONNECT_BY_PATH (atrvalue , ','), 2) csv
     FROM (SELECT '"'||atrvalue||'"' atrvalue, ROW_NUMBER () OVER (ORDER BY atrvalue ) rn,
                  COUNT (*) OVER () cnt
             FROM t1)
    WHERE rn = cnt
START WITH rn = 1
CONNECT BY rn = PRIOR rn + 1;


This will give us something like this list (the actual cost center codes are obfuscated):

"C_7420","C_4348","C_8253","C_7356","C_1478","C_4445","C_2653","C_8621","C_7429","C_5718","C_7111","C_7212","C_7102","C_8214","C_7105","C_2582","C_8279","C_5403","C_3336","C_5494","C_1699","C_7808","C_2921","C_1443","C_4880","C_9425","C_1508","C_4529","C_9989","C_4884","C_6871","C_9206","C_2550","C_5658","C_4455","C_9869","C_5594","C_9288","C_6026","C_3045","C_9264","C_3173","C_3180","C_7550","C_4140","C_6560","C_6802","C_3717","C_4475","C_9420","C_4808","C_8949","C_9966","C_4891","C_5648","C_8109","C_1219","C_5860","C_5416","C_5696","C_1201","C_7483","C_5781","C_3341","C_8140","C_1848","C_1449","C_9547","C_3318","C_3972","C_8261","C_4860","C_6658","C_9257","C_2750","C_6091","C_6316","C_1552","C_1497","C_4278","C_9596","C_2607","C_6416","C_4446","C_8388","C_3870","C_8727","C_2083","C_5332","C_7126","C_6998","C_9682","C_5234","C_7094","C_5246","C_6978","C_4928","C_5578","C_8033","C_6197","C_6687","C_4818","C_3574","C_7374","C_4368","C_5672","C_7632","C_7728","C_4644","C_9988","C_2692","C_6409","C_8017","C_9386","C_9059","C_5214","C_9930","C_2506","C_7060","C_4264","C_5640","C_5915","C_1436","C_3991","C_2381","C_1571","C_2850","C_6293","C_3125","C_5657","C_2275","C_3646","C_7077","C_4886","C_1253","C_3164","C_3677","C_6162","C_8123","C_2249","C_9296","C_8628","C_5577","C_8541","C_4581","C_8933","C_1420","C_9861","C_1403","C_3078","C_1654","C_7759","C_7014","C_7262","C_5283","C_4714","C_9501","C_2733","C_9351","C_6007","C_8832"


Now we want to iterate through multiple clusters, create data sources and run regressions. For that purpose we could write a stored procedure that will use a cursor of level 0 clusters. To get a set of level 0 clusters we can use the following query (we’ll pass a model name as a parameter into procedure):


SELECT ID FROM (
SELECT PARENT, ID, CONNECT_BY_ISLEAF ISLEAF, LEVEL CURRLEV FROM table(dbms_data_mining.get_model_details_km('CLUS_KM_1_2'))
   CONNECT BY PRIOR ID= PARENT
   START WITH NVL(PARENT,0) = 0
   )
WHERE ISLEAF=1
;


And the query to get a list of distinct attributes is:

select distinct
      a.attribute_name
from TABLE(dbms_data_mining.get_model_details_km('CLUS_KM_1_2'))  t,
    TABLE(t.rule.antecedent)  a
where 1=1
and t.id = 8
and a.attribute_confidence>0
;


Now by iterating through all the attributes and leaf clusters of a particular model we can create data sources for regression dynamically. We’ll use the following template to create the view:

CREATE OR REPLACE VIEW V_REG_MODELTOKEN_CLUSTERTOKEN
AS
SQLTOKEN
WHERE 1=1
CLUSTERFILTERTOKEN


MODELTOKEN,CLUSTERTOKEN,SQLTOKEN,CLUSTERFILTERTOKEN will be replaced in the stored procedure, and MODELTOKEN,SQLTOKEN will be passed into procedure as parameters.We will also need to define which dimension is a measure dimension used for dependent/independent variables in regression. In our case that is an account dimension. Since we pivoted that dimension (see previous post) and have accounts in columns, we can’t have a cluster rule (a where clause in other words) for measures dimension, so it is excluded from where clause.  In the end, when you run the following procedure, data sources for all clusters of a particular model should be created:


DECLARE
 VVIEWBASESQL CLOB;
 CURR_MODEL VARCHAR2(200);
 MEASURE_ATTR VARCHAR2(200);
BEGIN
 VVIEWBASESQL :=
               'SELECT
               "BUSINESSUNIT"||
               "COSTCENTER"||
               "CURRENCY"||
               "ENTITY"||
               "MNUM"||
               "PCC"||
               "YEAR" CASE_ID,
               BUSINESSUNIT,
               ENTITY,
               PCC,
               COSTCENTER,
               SCENARIO,
               VERSION,
               YEAR,
               HSP_RATES,
               CURRENCY,
               MNUM,
               "12345_ACC",
               "12346_ACC"
               FROM T_FACT_PIVOT_ACCOUNT
               where 1=1';
 CURR_MODEL := 'CLUS_KM_1_2';
 MEASURE_ATTR := 'ACCOUNT';

 CLUSTER_SOURCES(
   VVIEWBASESQL => VVIEWBASESQL,
   CURR_MODEL => CURR_MODEL,
   MEASURE_ATTR => MEASURE_ATTR
 );
--rollback;
END;



This is how the data sources would look like in SQLDeveloper:

And here’s the procedure itself:


create or  REPLACE PROCEDURE  "CLUSTER_SOURCES"
(
VVIEWBASESQL IN CLOB,
CURR_MODEL IN VARCHAR2,
MEASURE_ATTR IN VARCHAR2
)
as
--DECLARE
TYPE cur_TYPE IS REF CURSOR;
CLUSTER_CHILD VARCHAR2(200);
CLUSTER_ID NUMBER;
SQL_CLUSTERS_CURSOR VARCHAR2(4000);
CLUSTER_ATTR VARCHAR2(200);
SQL_ATTRIBUTES_CURSOR  VARCHAR2(4000);
SQL_RULE_CURSOR VARCHAR2(4000);
RULES_TEXT CLOB;
CLUSTER_RULE VARCHAR2(4000);
VVIEWTEXT CLOB;
VVIEWCURR CLOB;
cluster_cursor cur_TYPE;
attr_cursor cur_TYPE;
rule_cursor cur_TYPE;

BEGIN
VVIEWTEXT:='
CREATE OR REPLACE VIEW V_REG_MODELTOKEN_CLUSTERTOKEN
AS
SQLTOKEN
CLUSTERFILTERTOKEN';
SELECT   REPLACE(VVIEWTEXT,'MODELTOKEN',CURR_MODEL)  INTO VVIEWTEXT FROM dual;
SELECT   REPLACE(VVIEWTEXT,'SQLTOKEN',VVIEWBASESQL)  INTO VVIEWTEXT FROM dual;

SQL_CLUSTERS_CURSOR:='
SELECT ID FROM (
SELECT PARENT, ID, CONNECT_BY_ISLEAF ISLEAF, LEVEL CURRLEV FROM table(dbms_data_mining.get_model_details_km('''||CURR_MODEL||'''))
   CONNECT BY PRIOR ID= PARENT
   START WITH NVL(PARENT,0) = 0
   )
WHERE ISLEAF=1  ';


OPEN cluster_cursor FOR SQL_CLUSTERS_CURSOR;
LOOP
   FETCH cluster_cursor INTO
   CLUSTER_ID;
   EXIT WHEN cluster_cursor%NOTFOUND;

   SELECT   REPLACE(VVIEWTEXT,'CLUSTERTOKEN',CLUSTER_ID)  INTO VVIEWCURR FROM dual;

   RULES_TEXT:='';
   SQL_ATTRIBUTES_CURSOR:='
   select distinct  a.attribute_name
   FROM TABLE(dbms_data_mining.get_model_details_km('''||CURR_MODEL||'''))  t,
        TABLE(t.rule.antecedent)  a
   where 1=1
   and t.id = '||CLUSTER_ID||'
   and a.attribute_confidence>0';

   OPEN attr_cursor FOR SQL_ATTRIBUTES_CURSOR;
   LOOP
       FETCH attr_cursor INTO
       CLUSTER_ATTR;
       EXIT WHEN attr_cursor%NOTFOUND;
         IF CLUSTER_ATTR<>MEASURE_ATTR THEN
           SQL_RULE_CURSOR:='
           with t1 as (
           select t.id,
                  a.attribute_name,
                  a.conditional_operator,
                  nvl(a.attribute_str_value,
                  a.attribute_num_value) AS atrvalue,
                  a.attribute_support,
                  a.attribute_confidence
           FROM TABLE(dbms_data_mining.get_model_details_km('''||CURR_MODEL||'''))  t,
                TABLE(t.rule.antecedent)  a
           where 1=1
           and t.id = '||CLUSTER_ID||'
           and a.attribute_name='''||CLUSTER_ATTR||'''
           )

           SELECT SUBSTR (SYS_CONNECT_BY_PATH (atrvalue , '',''), 2) csv
                 FROM (SELECT ''"''||atrvalue||''"'' atrvalue, ROW_NUMBER () OVER (ORDER BY atrvalue ) rn,
                              COUNT (*) OVER () cnt
                         FROM t1)
                WHERE rn = cnt
           START WITH rn = 1
           CONNECT BY rn = PRIOR rn + 1';



           OPEN rule_cursor FOR SQL_RULE_CURSOR;
           LOOP
               FETCH rule_cursor INTO
               CLUSTER_RULE;
               EXIT WHEN rule_cursor%NOTFOUND;
               RULES_TEXT:=RULES_TEXT||' AND '||CLUSTER_ATTR||' IN ('||CLUSTER_RULE||')';
           END LOOP;
           CLOSE rule_cursor;
         END IF;
   END LOOP;
   CLOSE attr_cursor;
   select  REPLACE(RULES_TEXT,'"','''') into RULES_TEXT FROM dual;
--    dbms_output.put_line('RULES_TEXT FOR CLUSTER '||CLUSTER_ID||': '||RULES_TEXT);
   SELECT   REPLACE(VVIEWCURR,'CLUSTERFILTERTOKEN',RULES_TEXT)  INTO VVIEWCURR FROM dual;
--    dbms_output.put_line(VVIEWCURR);
   EXECUTE IMMEDIATE VVIEWCURR;
END LOOP;
CLOSE cluster_cursor;
END;
